Name: MaxP SW833
SKU: 9606
Availability: OutOfStock

Details

Up to 49 Amp for warning lights, siren, work lights and auxiliary devices.
8-button control panel with two-color backlight, build-in Buzzer and 10 indicator LED for traffic arrow.
3 inputs for Siren Park Kill, external buttons, signal detection and ignition detection application.
Programmable function for European Siren Interlock, Traffic Arrow or Scene buttons for quick activation,
Entering Standby Mode automatically after the controller has been inactivated for 1 or 15 minutes.

Additional information

LED Color	RED, BLUE, AMBER, WHITE, GREEN, BLUE/AMBER, RED/BLUE, RED/WHITE, AMBER/WHITE, AMBER/GREEN
Lens Color	Clear, Amber

Compliance:	ECE R10
Operating Voltage:	10-30VDC
Input Current:	max 45A/standby current 35mA
Output Voltage:	10-30VDC
Output Current:	(Positive) 15A x 1/10A x 2/10A x 1 (for Output 4~8) (Negative) 2A x2
Storage Temperature:	-40°C~75°C
